DSDF
Professionelle Drainage
The Dry Slope Drain Fleece It ensures reliable drainage under tubing tracks and mat ski slopes. It channels rainwater and meltwater away in a controlled manner, increases stability on the subsoil, and supports the controlled removal of microplastics.
Optimal floor coverage - Guaranteed water drainage.
Perfect coverage for mat ski slopes and multi-lane tubing runs
As a base for large mat ski areas or in combination with TubTrax M2 We have developed a novel drainage fleece. The Skitrax “Dry Slope Drain Fleece” (DSDF) is a hollow-nub drainage element with a friction-enhancing spun-spray coating on the underside. On soil and other substrates, the product remains in place even on slopes without additional fastening, up to an incline of approximately 1:3 (approximately 18° or 32%).
It can be delivered in rolls 12.5m long and 2.44m wide. A width of 4.88m and a length of 20m are only available for larger orders. Cutting to size in width as required is also only possible for larger orders.
This fleece can then be screwed between the two metal side elements of the TUBTRAX 2. This creates a professional, stable tubing liner with maximum cleanliness. Rainwater is channeled downwards and, if necessary, to the sides via the hollow nubs, thus protecting against undermining.
Perfect base for
SlopeTrax(Ski resort mats),TubTrax (Tubing tracks)
KartTrax (Ice karting with sliding and drifting)
.
The mats are secured to the ground using the DSDF system with special twisted ground stakes, which are easily installed using a drill. We also supply other types of geotextile fabric as needed.
- Optimal drainage of water
- Self-adhesive material
- Delivered in large rolls
(max. 50m x 4.95m) - Can be laid out independently
- Skitrax mats are coming to the DSDF
- Special, twisted ground stakes secure the system.
